Custom
Reel Trailers Across USA
If the reel trailer you are looking for is not listed, please let us know!
We offer a wide-range of Reel Trailer
We use only the highest quality American-made materials and are prepared to match any price.
NON-HYDRAULIC REGULAR
- Capacity: 7,000 pounds
- Type: Cable reel trailer
- Reel Position: Reel centered over the wheels for minimal tongue weight
- Construction: Trailer frame, internal supports, and uprights are made of steel tubing (for maximum strength, durability, and to minimize flex)
- Reel Height Positions: 2 different height positions for the reel
- Reel Stabilization: Plates to center the reel for better stability and improved performance during use
- Coupler: Adjustable ball coupler or pintle ring
- Safety Chains: Included
- Electrical Connector: 4-pin plug
- Lighting: LED lights at the rear
- Elevation Levels: Two or three levels of elevation
- Brakes: 10″ electric brakes
- Color: Available in various colors
REEL TRAILER HYDRAULICS
- Hydraulic Pumps: Two manual hydraulic pumps
- Mounting: Bolted to a drop-leg jack
- Brakes: 12-volt electric brakes
- Breakaway Kit: Included
- Lights: LED lights
- Electrical Connector: 7-pin RV plug or 6-pin round connector, and safety chains
- Reel Adjustment: 2 pumps for reel adjustment on uneven terrain
- Center of Gravity: Low
- Construction: Sturdy and reliable
- Reel Diameter: 120 inches
- Reel Width/Area: 60 inches
- Payload Capacity: 7,000 lbs
- Overall Length: 130 inches
- Overall Width: 110 inches
REEL TRAILER HYDRAULICS
- Hydraulic Pumps: Two manual hydraulic pumps
- Mounting: Bolted to a drop-leg jack
- Brakes: 12-volt electric brakes
- Breakaway Kit: Included
- Lights: LED lights
- Electrical Connector: 7-pin RV plug or 6-pin round connector, and safety chains
- Reel Adjustment: 2 pumps for reel adjustment on uneven terrain
- Center of Gravity: Low
- Construction: Sturdy and reliable
- Reel Diameter: 120 inches
- Reel Width/Area: 60 inches
- Payload Capacity: 7,000 lbs
- Overall Length: 130 inches
- Overall Width: 110 inches
DOUBLE REEL TRAILER & TRIPLE REEL TRAILER
- Capacity: 14,000 lbs
- Hitch Bar: 2.5 inches
- Axles: Heavy-duty dual axle with an option for a triple axle
- Construction: Trailer frame, internal supports, and uprights are made of steel tubing (for maximum strength, durability, and to minimize flex)
- Reel Diameter: Up to 124 inches
- Reel Stabilization: Plates to center the reel for better stability and improved performance during use
- Coupler: Adjustable ball coupler or 5-position pivot ring
- Safety Chains: Included
- Electrical Connector: 7-pin plug
- Lighting: LED lights at the rear
- Brakes: 12-inch electric brakes
